Healicom FCA800 Fully Automated Biochemistry Analyzer

Healicom FCA800 Fully Automated Biochemistry Analyzer

৳ 3,300,000.00

Type: Biochemical Analysis System
Brand Name: Healicom
Model Number: FCA800
Place of Origin: Jiangsu, China
Instrument classification: Class II
Warranty: 1 Year

Call for detail: 01842-756014

Categories: Biochemistry Analyzer, Medical Equipment

Description
Reviews (0)

Healicom FCA800 Fully Automated Biochemistry Analyzer

Quick Details

Type: Biochemical Analysis System
Brand Name: Healicom
Model Number: FCA800
Place of Origin: Jiangsu, China
Instrument classification: Class II
Warranty: 1 Year
After-sale Service: Online technical support
Analytical System: random Access
Throughput: 960 Thr(include ISE), 800 T/Hr(biochemical test only)
Sample capacity: 2 x 92 primary tube or micro serum cup
Sample volume: 1.0- 100μL in 0.1μLl/step
Reagent volume: 1-500μL in 0.1 μL/step

Products Description

FCA800 Clinical Fully Automated Biochemistry Chemistry Analyzer

Features ● High throughput random acess… ● 800 tests/hr or 960 tests/hr (with ISE mould). ● New style software, more friendly, efficient and convenient. ● Water-bath incubation technology ensures accurate reaction temperature. ● Frequency conversion technology makes movement more stable,reliable and lower noise. ● Perfect self-test and position auto-locating function minimize mechanical error. ● Auto stand-by function for saving energy consuming and 24 hours ready for work. ● Perfect Instrument-Reagent-Control/Calibrator system ensures the results with good traceability and coherence.

ISE module is optional, test various ion items at the same time with accurate results and stable performance.

Advanced high sensitive test technology.

High quality plastic cuvette(quartz glass cuvette available on request).

High resolution concave grating system, wavelength range 340-800nm, multi-wavelength polychromatic assay at the same time.

Eight channels washing station for each cuvette cleaning, automatic record and deduct cuvette blank value. Heavy washing function available for “dirt cuvette” to ensure each cuvette perfectly clean.

High accuracy diluter, advanced sealed and connecting technology to guarantee accurate sampling.

Two separate reagent chambers with independent refrigerator.

Technical Specifications

Internal and external nano treated probe effectively reduce probe residual and carry over.

Model	FCA800	FCA600
Assay types	Random access
Throughput	960 Thr(include ISE), 800 T/Hr(biochemical test only)	760 Thr(include ISE), 600 THr(biochemical test only)
Analytical methods	End point, Kinetic(Rate), Fixed time, Single standard, Multi-standard, Single wavelength assay, Bichromatic, Bi-reagent assay, Serum blank assay, Immunoturbidimetric assay and ISE assay (KNaCaCAPH)
Sample capacity	2 x 92 primary tube or micro serum cup	1 x 92 primary tube or micro serum cup
Sample/reagent probe	With liquid level sensor, automatically checking and tracking reagent allowance ability, internal and external nano treated, stereoscopic collision protection, plugging probe checking ability
Sample volume	1.0- 100μL in 0.1 μL/step
Reagent volume	1-500μL in 0.1 μL/step
Reagent tray	2 reagent trayes, barcode scaner available (on request), R3/R4 assay models available
Reagent refrigerater	2-8℃, 24 hrs available
Reading Cuvette	160 cuvettes, made of ultraviolet transmitable plastic(or quartz glass cuvettes available on request)
Reaction volume	Minimum 120 μl
Reaction disc temp.	Water bath system, 37土0.1″C,(air bath on request)
Cuvette cleaning	Automatical warm water washing station with 8 channels, blank reading for ensuring each cuvette well cleaned before using. Smart detergent clean for high contamination cuvette and probe, efficiently decreasing carry-over
Carry-over	Less than 0.05%
Monochromator	Concave grating
Wavelength range	340-810nm
Alarm	Automatic alarm for lack of reagent, sample，water, or waste filled and other errors, showing the info on monitor
Mixer	2 nano-surface treated mixing probers, with automatic warm water washing station for each one
Quality control	Multi-level QC for the same item automatically monitoring and alarming if the results out of control
Assay Linearity range	Wide linearity range measuring, also with automatically diluting function for high value sample
Calibration	Single or multi-points calibration, supporting linear and nonlinear assay
Data processing	Powerful software for calculating, blanking, multi-analysis, data reviewing, QC and results management, on line monitoring, editing etc.
Data storage	Long-term storage, storage capacity upon PC hard disc
Print	Multi report formats and user-self- defined report format are available
Power supply	AC 110V/60Hz or 220V/50Hz
Dimensions	1200mm x 900mm x 1100mm
